Ductile, tough thermoplastic alloy
Very low coefficients of surface friction in dry operation
High holding times
Vibration dampening
Tough in high-frequency angular motions
Excellent wear resistance
Maintenance-free dry operation
Excellent resistance against chemicals
Suitable for rotary, oscillating and linear movements
Also suitable for soft shafts
Lightweight
Ideal friction partner for iglidur® W300 spherical balls
High mechanical stability
Shock- and impact-resistant
Resistant to corrosion
Chemical resistant
Shape stability
Temperature-resistant up to +200 °C
igubal® | Operating temperature | |
---|---|---|
standard | HT-Version | |
Lower | -30 °C | -40 °C |
Upper, long-term | +80 °C | +200 °C |
Upper, short-term | +120 °C | +240 °C |
Screw thread designation | Pitch [mm] |
---|---|
M 2 | 0,40 |
M 3 | 0,50 |
M 4 | 0,70 |
M 5 | 0,80 |
M 6 | 1,00 |
M 8 | 1,25 |
M 10 | 1,50 |
M 10 F | 1,25 |
M 12 | 1,75 |
M 12 F | 1,25 |
M 14 | 2,00 |
M 16 | 2,00 |
M 16 F | 1,50 |
M 18 | 1,50 |
M 20 | 1,50 |
M 20 | 2,50 |
M 22 | 1,50 |
M 24 | 2,00 |
M 27 | 2,00 |
M 30 | 2,00 |
Medium | Resistance | |
---|---|---|
standard | HT-Version | |
Alcohols | + to 0 | + |
Hydrocarbons | + | + |
Fats, oils, without additives | + | + |
Fuels | + | + |
Diluted acids | 0 to - | + to 0 |
Strong acids | - | + to - |
Diluted bases | + | + |
Strong bases | 0 | + |
Nominal diameter [mm] | ||
---|---|---|
Gage drops | Gage hangs | |
0 to 3 | x,01 | x,05 |
> 3 to 6 | x,02 | x,07 |
> 6 to 10 | x,02 | x,08 |
> 10 to 18 | x,03 | x,10 |
> 18 to 30 | x,04 | x,12 |
> 30 to 50 | x,05 | x,15 |
